XL285-1.2

Voltage References

Application

Handheld instruments
Handheld devices
Battery systems
Current loop devices

View details View datasheet More products

Overview

Product details

XL285-1.2 is a micropower double-terminal bandgap Zener diode launched by Xinluda. They have an operating current range of 10μA to 20mA and have extremely low dynamic impedance and good temperature stability. Their on-chip trimming function can be used in applications that require strict voltage tolerance. The rated operating temperature range of XL285-1.2 is -40℃ to 85℃. XL285-1.2 adopts hermetic TO package. XL285-1.2 also adopts low-cost TO-92 package as well as SOIC and SOT-23 package

Features

● 2% initial tolerance
● Operating current range 10μA to 20mA
● Dynamic impedance 1Ω
● Low temperature coefficient
● Low voltage reference: 1.235V

Apply for samples

Product	Package	Operating temperature	QTY.	ROHS	Apply for samples
XL285-1.2	SOP-8	-40℃~+85℃	2500 pcs/Reel	✔	Sample application
