Overview

Product details

    This BCD to decimal decoder/driver consists of eight inverters and ten four-input NAND gates. The inverters are connected in pairs to make the BCD input data available for decoding by the NAND gates. Full decoding of valid BCD input logic ensures that all outputs remain off for all invalid binary input conditions. This decoder features high performance n-p-n output transistors and is designed for use as an indicator/relay driver or open-loop logic circuit driver
