XL1050

High-speed CAN transceiver

Application

Automotive electronics
Point-to-point and point-to-multipoint communications
Industrial control automation
Security systems
Intelligent instrumentation
Road traffic control automation
Building automation systems
Serial servers
Level converter

View details View datasheet More products

Overview

Product details

The XL1040 is the interface between the Controller Area Network (CAN) protocol controller and the physical bus. It is primarily intended for high speed applications, up to 1 M Baud, in passenger cars. The device provides differential transmit capability to the bus and differential receive capability to the CAN controller.

Features

● Fully compatible with the ISO 11898 standard
● High speed (up to 1 MBaud)
● Very low-current standby mode with remote wake-up capability via the bus
● Differential receiver with high common-mode range for ElectroMagnetic Immunity (EMI)
● Transceiver in unpowered state disengages
● from the bus (zero load) At least 110 nodes can be connected
● Transmit Data (TXD) dominant time-out function
● Bus pins protected against transients in automotive environments
● Thermally protected
● Operating voltage range: VCC = 5V ± 10%

Apply for samples

Product	Package	Operating temperature	QTY.	ROHS	Apply for samples
XL1050	SOP-8	2500 pcs/Reel	-40℃~+85℃	✔	Sample application
