XD124

Low-power quad operational amplifiers

Application

DC amplifier module
Traditional operational amplifier circuit
Transducer amplifier

View details View datasheet More products

Overview

Product details

The XD124 consist of four independent, high gain operational amplifiers with frequency compensation implemented internally. They operate from a single power supply over a wide range of voltages. Operation from split power supplies is also possible and the low-power supply current drain is independent of the magnitude of the power supply voltage.

Features

● Wide gain bandwidth: 1.3 MHz
● Input common mode voltage range includes ground
● Large voltage gain: 100 dB
● Very low supply current/amplifier: 375 µA
● Low input bias current: 20 nA
● Low input voltage: 3 mV max.
● Low input offset current: 2 nA
● Wide power supply range: – Single supply: 3 V to 30 V – Dual supplies: ±1.5 V to ±15 V

Apply for samples

Product	Package	Operating temperature	QTY.	ROHS	Apply for samples
XD124	DIP-14	-40℃~+85℃	1000 pcs/Tube	✔	Sample application
