XD3403

Operational Amplifiers - Op Amps Quad Low Power

Application

Motor or servo motor control
Regulated power supply
Measuring instruments and signal amplification

View details View datasheet More products

Overview

Product details

The XD3403 quad op amps have performance similar to the XD741. But have several distinct advantages. They are designed to operate from a single supply over a voltage range of 3 V to 36 V. They can also be operated from a split supply if the voltage difference between the two supplies is 3 V to 36 V. The common-mode input range includes the negative supply. The output range is from the negative supply to VCC - 1.5 V. The quiescent supply current is less than half that of the XD741. The XD3403 is characterized for operation from 0°C to 70°C.

Features

● Wide supply voltage range
● single supply voltage range
● 3V to 36V or dual supply
● Class AB output stage
● True differential input stage
● Low input bias current
● Internal frequency compensation
● Short-circuit protection

Apply for samples

Product	Package	Operating temperature	QTY.	ROHS	Apply for samples
XD3403	DIP-14	0℃~+70℃	1000 pcs/Tube	✔	Sample application
