XD74LS85
Logic Comparators 4-bit binary or BCD Magnitude Comparator
Computer
Digital control
Communications
This four-bit magnitude comparator performs comparisons of straight binary and straight BCD (8-4-2-1) codes. Three fully decoded decisions are made for two 4-bit words (A, B) and are externally available at three outputs. The device is fully expandable to any number of bits without the need for external gates. Longer words can be compared by cascading the comparators.
● Low power consumption
Product | Package | Operating temperature | QTY. | ROHS | Apply for samples |
---|---|---|---|---|---|
XD74LS85 | DIP-16 | 0℃~+70℃ | 1000 pcs/Tube | ✔ | Sample application |
