XD74LS06

Hex Inverter Buffers and Drivers With Open-Collector High-Voltage Outputs

Application

Factory Automation
Building Automation
Line Drivers
Electronic Point of Sale
Desktop or Notebook PCs

View details View datasheet More products

Overview

Product details

The XL/XD74LS06 devices feature high-voltage, open- collector outputs to interface with high-level circuits (such as MOS), or for driving high-current loads, and also are characterized for use as inverter buffers for driving TTL inputs. The XL/XD74LS06 devices have a rated output voltage of 30 V.

Features

● Convert TTL Voltage Levels to MOS Levels
● High Sink-Current Capability
● Input Clamping Diodes Simplify System Design
● Open-Collector Driver for Indicator Lamps and Relays
● Inputs Fully Compatible With Most TTL Circuits

Apply for samples

Product	Package	Operating temperature	QTY.	ROHS	Apply for samples
XD74LS06	DIP-14	0℃~+70℃	1000pcs/Tube	✔	Sample application
