XD74LS83

4-bit binary full adder with fast carry

Application

Four-bit amplitude comparator

View details View datasheet More products

Overview

Product details

This 4-bit magnitude comparator performs comparisons of straight binary and straight BCD (8-4-2-1) codes. Three fully decoded decisions are made for two 4-bit words (A, B) and are available externally at three outputs. The device is fully scalable to any number of bits without the need for external gates. Longer words can be compared by cascading comparators. A>B, A

Features

● Internal Look-Ahead for Fast Counting
● Carry Output for n-Bit Cascading
● Synchronous Counting
● Synchronously Programmable
● Load Control Line
● Diode-Clamped Inputs

Apply for samples

Product	Package	Operating temperature	QTY.	ROHS	Apply for samples
XD74LS83	DIP-16	0℃~+70℃	1000 pcs/Tube	✔	Sample application
