XD74LS42

4-Line BCD to 10-Line Decimal Decoder

Application

Industrial Applications

View details View datasheet More products

Overview

Product details

This monolithic decimal decoder consists of eight inverters and ten four-input NAND gates. The inverters are connected in pairs, making the BCD input data available for NAND gate decoding. Full decoding of valid input logic ensures that all outputs remain off under all invalid input conditions.

Features

● All Outputs Are High for Invalid Input Conditions
● Also for Application as： 4-Line-to-16-Line Decoders 3-Line-to-8-Line Decoders
● Diode-Clamped Inputs

Apply for samples

Product	Package	Operating temperature	QTY.	ROHS	Apply for samples
XD74LS42	DIP-16	0℃~+70℃	1000 pcs/Tube	✔	Sample application
